Hirose has launched the world’s lowest profile Nano SIM card connector. The KP13B Nano SIM card connector reduces the required printed circuit board (PCB) mounting space by up to 26% compared to other products on the market. The space-savings connector simplifies designs in digital cameras, digital video cameras, laptops, printers, smart phones, televisions and more.
The connector has a card detection feature and is designed to prevent incorrect card insertion. This ensures proper mating and protect contacts from damage. The user-friendly card connector is easy to insert / eject and offers 5000 mating cycles. An exposed terminal design simplifies examination of the connector contacts via automated optical inspection.
The push-push KP13B Series is only 13.6 mm long, 11.5 mm wide and 1.18 mm high.
The KP13B Series has an operating temperature range of -30 degree C to +85 degree C, a rated current of 0.5A and a rated voltage of 10V.
For additional information about the KP13B Series connectors, please visit:
https://www.hirose.com/product/series/KP13
