Diodes Incorporated Reduces MOSFET Off-board Height by 50%

Diodes Incorporated has launched a line of high-efficiency N- and P-channel MOSFETs in low-profile DFN2020-6 packages. With an off-board height of only 0.4mm and a footprint of 4mm2, the DFN2020H4 packaged DMP2039UFDE4, a -25V rated P-channel device, is 50% thinner than competing devices. The other MOSFETs in the series are provided in the 0.5mm high DFN2020E package, which is 20% thinner than the common 0.6mm high alternatives. Targeted at load-switching applications, the DMP2039UFDE4 also provides circuit designers with 3kV protection against human-borne electrostatic discharge. The new MOSFETs' low typical RDS(on), for example just 13m? at a VGS of 4.5V for the -12V P-channel DMP1022UFDE, means conduction losses can also be minimized in battery-charging applications. The 20V N-channel DMN2013UFDE makes an ideal load switch or high-speed switch in DC/DC buck and boost converters and again offers a high 2kV ESD protection rating. Operating at a VDS of 60V, the DMN6040UFDE is one of the first high-voltage MOSFETs to be introduced in the DFN2020 package and suits small form-factor industrial and HVAC controls. Particularly well-suited to ultra-slim portable product designs, such as smart phones, tablets and digital cameras, the initial series of nine MOSFETs is comprised of -12V, -20V, -25V and -40V P-channel and 12V, 20V and 60V N-channel parts. The low-profile DFN2020 packaged N- and P-channel MOSFETs are priced from $0.15 USD each in 3K quantities. www.diodes.com
